Packing press 50P1 with shift press cage
150 kg/h. Packing press with sliding juice basin.
Product Documents
Download PDF
Description
Packing press with moveable juice basin (sliding carriage) and hydraulic power unit. Easy and safe operation thanks to automatic pressure relief valve on hydraulic power unit.
TECHNICAL DATA
| Nominal rating kg/h | 150 kg/h |
| Motor rating | 1,1 (1,5) kW (PS) |
| Connected load | Various Voltages Available |
| Electrical protection | T.B.D. |
| Length | 1100 mm |
| Width | 990 mm |
| Height | 1430 mm |
| Discharge height | 1080 mm |
| Weight | 160 kg |
| Material | Packer frame and juice basin in 1.4301 / AISI 304 |
| Press force | 14 to |
| Press pressure | 380 bar |
| Juice yield | 75 % |
| Connection for juice outlet | Ø30mm |
| Height juice outlet | 470 mm |
| Scope of supply | 7 press cloths 70×70 cm, 8 press inserts in acacia wood 41×41 cm |
