Packing press 50P1 with shift press cage

Sorry, this product is not available in your country.

150 kg/h. Packing press with sliding juice basin.

Product Documents

Sorry, this product is unavailable or Cellar-Tek is not the distributor in your country. (We cater to Canada & North America.) Please feel free to inquire about local distribution contact information.
SKU: 340 Category:
Share On:

Product Description

Packing press with moveable juice basin (sliding carriage) and hydraulic power unit. Easy and safe operation thanks to automatic pressure relief valve on hydraulic power unit.

TECHNICAL DATA

Nominal rating kg/h150 kg/h
Motor rating1,1 (1,5) kW (PS)
Connected loadVarious Voltages Available
Electrical protectionT.B.D.
Length1100 mm
Width990 mm
Height1430 mm
Discharge height1080 mm
Weight160 kg
MaterialPacker frame and juice basin in 1.4301 / AISI 304
Press force14 to
Press pressure380 bar
Juice yield75 %
Connection for juice outletØ30mm
Height juice outlet470 mm
Scope of supply7 press cloths 70×70 cm, 8 press inserts in acacia wood 41×41 cm
